MICOPERI 61 SELF ELEVATING PLATFORM
MAIN DATA
|
IMO number |
8757881 |
|
Gross tonnage |
1341 GT |
|
Net tonnage |
402 NT |
|
Length overall |
40.60 m |
|
Breadth |
28.65 m |
|
Maximum draft |
1.90 m |
|
Depth |
3.66 m |
|
Maximum operative water depth |
28.0 m |
|
Legs |
4 x Ø 1800 mm x 47 m length |
|
Air jack system |
4 x Air jacks De Long - 5186 kN |
|
Sors |
Schramm diesel air-compressors |
|
Registry of Classification |
RINA |
|
Class |
Self Elevating Platform |
MOORING EQUIPMENT
|
Anchor winches |
4 x motor winches 200 kN pull 2 x electrical-winches 100 kN pull |
|
Anchors |
6 x 5 t - Hall type |
COMMUNICATION EQUIPMENT
|
VHF |
Sailor RT 2048 Compact |
ACCOMMODATION
|
Modern fully conditioned and heated accommodation as follows: |
|
|
2x1 person |
|
|
9 x2 persons |
|
|
5x4 persons |
|
|
Hospital n.1 |
|
|
Mess-room 40 persons |
|
VIDEO ARCHIVE
DOWNLOAD FILES
Download the brochure of this ship whit all the technical informations and specifications
|
Length overall |
183.3m |
|
Length between perpendiculars |
173.2m |
|
Breadth |
36.0m |
|
Depth from deck |
13.0m |
|
Draft |
5.5 – 8.9m |
|
Gross tonnage |
24,822t |
|
Deck load |
<5,000t |
|
Deck space |
2,560m2 |
|
Free deck height |
20m (to boom in rest) |
